DC24V flexible LED strip SMD2835 120LED

产品名称 Name 2835 high voltage flexible strip 产品型号 NO. LE-SX120-24V-2835 主要材质 Material PVC+Line+FPCB 产品尺寸 Size 13*7mm 发光角度 Beam angle 120 LED型号 LED Model SMD 2835 LED数量 LED S 60D 单颗LED光通量 Luminous flux 22-24LM LED颜色 LED Colour 3000K/4000K/6000K/R/G/B/Y/P LED功率 LED Power 0.2W/LED PCB板宽 PCB Width 8mm PCB厚度 PCB thickness 1盎司 35铜厚 1 ounce 35 mm 功率 Power 10w1w 电压 voltage 24v 剪切单元 Cuttable length 0.5M/1M 防水等级 Waterproofing IP65 标准包装 Packing 50m/R 纸箱尺寸 Packing size 33.5*33.5*11.5 纸箱毛重 G.W. 6KG 必需配件 Accessories Power cord, End Cap， Mounting Clip(suggest need 1pc for a 0.5M)

Request a quote
Close
Enter your details and submit
We'll aim to get back to your with a quote within 24hrs
产品名称                 Name 2835 high voltage flexible strip
产品型号               NO. LE-SX120-24V-2835
主要材质         Material   PVC+Line+FPCB
产品尺寸                Size 13*7mm
发光角度           Beam angle 120°
LED型号              LED Model  SMD  2835
LED数量               LED S  60D
单颗LED光通量 Luminous flux 22-24LM
LED颜色              LED Colour 3000K/4000K/6000K/R/G/B/Y/P
LED功率               LED Power 0.2W/LED
PCB板宽              PCB Width 8mm
PCB厚度             PCB thickness 1盎司 35铜厚 1 ounce 35 mm
功率                   Power 10w±1w
电压                  voltage 24v
剪切单元        Cuttable length 0.5M/1M
防水等级 Waterproofing IP65
标准包装         Packing 50m/R
纸箱尺寸         Packing size 33.5*33.5*11.5
纸箱毛重            G.W. 6KG
必需配件 Accessories Power cord, End Cap， Mounting Clip(suggest need 1pc for a 0.5M)
