Flexible Led Strip Lights 220v 230v 110v Waterproof Led Strip 50 Meters 220v

1. Easy to install, no need for external power adapter, directly use AC110V/220V.

2. No pressure drop, consistent brightness at 50 meters.

3. PVC extrusion process, two moldings, protection grade IP65, high safety factor, can be used indoors and outdoors.

4. Flexible light strip, no restrictions on curved corners.

5. Environmentally friendly rubber, UV-proof and fire-proof.

6. Passed CE, Rohs certification.

Request a quote
Close
Enter your details and submit
We'll aim to get back to your with a quote within 24hrs
※  Product accessories：power cord, tail plug, buckle, middle indirection


※ Product schematic diagram:


※ Instructions for use:

※ Product packaging diagram:
One roll of 50 meters, one roll one box. Carton size: 33.5*33.5*15.5 Material: K=K

产品名称                 Name 5050 high voltage flexible strip
产品型号               NO. LE-SX60-220V-5050
主要材质         Material   PVC+Line+FPCB
产品尺寸                Size 13*7mm
发光角度           Beam angle 120°
LED型号              LED Model  SMD  5050
LED数量               LED S  60D
单颗LED光通量 Luminous flux 22-24LM
LED颜色              LED Colour 3000K/4000K/6000K/R/G/B/Y/P
LED功率               LED Power 0.2W/LED
PCB板宽              PCB Width 8mm
PCB厚度             PCB thickness 1盎司 35铜厚 1 ounce 35 mm
功率                   Power 8w±1w
电压                  voltage 100-130v/220-240v
剪切单元        Cuttable length 0.5m/1m
防水等级 Waterproofing IP65
标准包装         Packing 50m/R
纸箱尺寸         Packing size 33.5*33.5*11.5
纸箱毛重            G.W. 6KG
必需配件 Accessories Power cord, End Cap， Mounting Clip(suggest need 1pc for a 0.5M)
